| 蓄电池型号 | 额定电压(V) | 额定容量C100 (Ah, 20℃, 1.80Vpc) | 电池尺寸 | |||
| 长(L) /mm | 宽(b/W) /mm | 总高(H) /mm | ||||
| S12/230 A | 12 | 230 | 518 | 274 | 238 | |
| S12/130 A | 12 | 130 | 286 | 269 | 230 | |
| S12/90 A | 12 | 90 | 330 | 171 | 236 | |
| S12/85 A | 12 | 85 | 353 | 175 | 190 | |
| S12/60 A | 12 | 60 | 261 | 136 | 230 | |
| S12/41 A | 12 | 41 | 210 | 175 | 175 | |
| S12/32 G6 | 12 | 32 | 197 | 132 | 184 | |
| S12/27 G5 | 12 | 27 | 167 | 176 | 126 | |
| S12/17 G5 | 12 | 17 | 181 | 76 | 167 | |
| S12/6.6 S | 12 | 6.6 | 152 | 66 | 98 | |
